Product Details:
|
| Pore Size: | 20-50nm | Melting Point: | >1600°C |
|---|---|---|---|
| Color: | White | Applications: | Insulation, Thermal Protection, Catalyst Supports |
| Boiling Point: | 3000°C | Bulk Density: | 0.2 G/cm3 |
| Chemical Stability: | Excellent | Dielectric Constant: | 3.2 |
| Material: | Silica | Melting Point: | 1200°C |
| Particle Size: | 1-3 μm | Product Name: | Aerogel Powder |
| Purity: | 99.9% | Refractive Index: | 1.45 |
| Solubility: | Insoluble In Water | Surface Area: | 200 M2/g |
| Thermal Conductivity: | 0.03 W/mK | ||
| Highlight: | Low Thermal Conductivity Aerogel Powder,99.9% Purity Aerogel Powder,Insulation Aerogel Powder |
||
AG-D Aerogel Powder:High Specific Surface
AG-D Aerogel Powder Product properties
Unique nanoporous structure
The internal structure of aerogel is composed of cross-linked nanoparticles, which are connected to form a skeleton and form a unique porous network structure with an aperture of 20-50 nm. Therefore, aerogel has low density (≤ 0.16 mg/cm3), high specific surface area (400-1000 m2/g), high porosity (90%-99.8%) and low thermal conductivity (~0.012 WM-1K-1).
Aerogel has many excellent properties
Aerogel is a kind of material with nanoporous reticular structure. Due to its unique nanostructure, aerogel has unique excellent properties in thermal, acoustic, mechanical and optical aspects, and has many excellent properties such as thermal insulation, sound insulation and noise reduction, infrared absorption, catalysis and environmental protection.
Physical and chemical properties
| Item | Value |
| Specific surface area | 600-800㎡/g |
| Bulk density | 40-60 kg/m³ |
| Thermal conductivity (25℃)W/(m K) ≤ | 0.018 |
| Porosity factor ≥ | 90% |
| Pore size ≥ | 20-50nm |
| Particle size < | 15-50μm |
| Hydrophobicity | 99.9% |
| Sintering point | 600-800°C |
| Melting point | 1600°C |
| Boiling point | 2230°C |
| Color | White/Semitransparent |
| Surface property | Hydrophobic |
| Solubility in water | Insoluble |
| Odor | No special odor |
| Packing | 8kg/drum, or 7-10kg/bag |
Application:
Thermal insulation material, sound insulation materials, coatings, bulletproof material, low density test material etc.
